When it comes to beadlock wheels, not all designs are created equal. For overlanders who push the limits of weight, terrain, and distance, the THRET® 602 Cast Beadlock wheel offers unmatched reliability.
At just 33.8 lbs, this 17×9 wheel combines a durable cast aluminum barrel with a forged beadlock ring and 24 Grade 8 bolts. The result? A load rating of 3,640 lbs per wheel — far beyond the industry average.
Whether you’re carrying rooftop tents, recovery gear, or full trail armor, you can trust the 602 to hold the line. Just keep your torque checked, your PSI smart, and your goals set to send.
-
PRECISION SERIES602 Beadlock Satin Bronze – Cast
5Lug | 6Lug Fitments Available
THRET® 602 Cast Beadlock Wheel Specifications
Model: 602 Cast Beadlock Wheel
Size: 17×9
Brand: THRET®
Beadlock Design & Build
- Beadlock Type: True mechanical cast beadlock with forged aluminum ring
- Bolt Count: 24 bolts per ring
- Bolt Torque Spec: 20–25 ft-lbs
- Bolt Material: Grade 8 hardware
- Wheel Weight: 33.8 lbs (including beadlock ring and hardware)
Load Rating
- Maximum Load Rating: 3,640 lbs per wheel
- Per Corner Load Handling: Suitable for heavy-duty off-road and overland applications, supporting up to 3,640 lbs per wheel
Best Practices for Overlanding with Beadlocks (Off-Road Use Only)
- Maintain a 10–15% buffer below max load — around 3,100–3,200 lbs per wheel is ideal
- Retorque bolts every few hundred miles of hard wheeling
- Monitor tire pressure — low PSI increases side loading on the ring
- Use blue thread locker to prevent bolt loosening from vibration
- Not DOT-approved for highway use in most states
